Direct velocity output
A 500 mV/in/s sensitivity supports familiar vibration-velocity measurement and trending.
Item NO.:
9200-02-01-10-00Order(MOQ):
1Goods Stock:
27Payment:
T/TLead Time：
In stockWeight:
0.46KGDimension:
11.5x4x4cmDescription:
TRANSDUCERPrice:
AskFast, accurate industrial sourcing - share the model, quantity and delivery country.
A two-wire moving-coil velocity transducer configured for a 45-degree mounting angle, top connector and M10 x 1 base.
Bently Nevada 9200-02-01-10-00 is a two-wire Seismoprobe velocity transducer for measuring absolute vibration on bearing housings, machine casings and structural points. Its moving-coil design produces an output directly proportional to vibration velocity and can support continuous monitoring or periodic measurement.
This order code specifies a 45-degree mounting orientation with a 4.5 Hz minimum operating frequency, a top-mounted connector, a circular M10 x 1 mounting base and no agency approval option. These details matter to the physical installation and the expected response at the measurement point.
A 500 mV/in/s sensitivity supports familiar vibration-velocity measurement and trending.
The 45-degree calibration orientation and top connector suit installations designed around this specific arrangement.
The metric base option gives buyers a clear mechanical reference when replacing an installed transducer.
For a dependable match, include the complete 9200-02-01-10-00 code, a photo of the mounting point, the connector or cable arrangement and the connected monitor input. Similar 9200 units can differ in calibrated angle, minimum frequency, connector direction, base style and approval option.
| Product family | 9200 two-wire Seismoprobe velocity transducer |
|---|---|
| Sensitivity | 20 mV/mm/s (500 mV/in/s), +/-5% |
| Mounting angle | 45 degrees, +/-2.5 degrees |
| Minimum operating frequency | 4.5 Hz (270 cpm) |
| Connector option | Top mount, no integral cable |
| Mounting base | Circular M10 x 1 stud |
| Agency approval option | No approvals |
| Operating temperature | -29°C to +121°C |
| Place of shipment | Xiamen, China |
| Delivery Time | 1-3 days |
| Quantity | 100% New Original |
| Minimum Order Quantity | 1pc |
The transducer is calibrated for its specified mounting angle, so a correct orientation supports the expected low-frequency response.
The top connector, two-wire circuit and 10 kOhm calibration load are useful references when assessing the receiving monitor channel.
Used for casing and bearing-housing velocity measurement on turbines, compressors, pumps, fans and other rotating equipment where absolute vibration is the required parameter.
Yes, when the existing point also uses the specified 45-degree orientation, top connector and M10 x 1 base. ApterPLC can compare the mounting photo and label before quotation.
We recommend matching the original calibration angle because orientation affects low-frequency response. A different 9200 configuration may be more suitable, and our team can help compare the installed geometry.
It is intended for a two-wire velocity circuit, provided the monitor input suits the published sensitivity and load. Sharing the monitor model lets ApterPLC review the signal-chain fit.
Its published minimum operating frequency is 4.5 Hz. Comparing the expected vibration frequency with that limit helps buyers avoid selecting a sensor that cannot cover the required measurement range.
This configuration uses a top-mounted connector, so connector direction and surrounding clearance should agree with the installed point. A photo helps our team identify a practical replacement.
The complete label, mounting photo, connector or cable details, monitor input, quantity and destination give our team a clear basis for an accurate quotation.
Precise model supportClear model comparison helps reduce ordering risk and avoid preventable delays.
New original supplyCurrent, discontinued and hard-to-find automation parts for planned maintenance.
Responsive coordinationFast quotation, delivery support and practical post-purchase communication.
Manufacturer-recognized family names used in catalogs and service records.
Apter provides a 1-year warranty on every item we sell. Our team remains available for delivery coordination, receipt questions and after-sales communication.
Apter independently supplies industrial automation parts, including current and discontinued products. Product names, images and trademarks help customers identify the items they need and remain the property of their respective owners. Apter is not an authorized distributor or representative of those manufacturers.
We carefully match available technical documents to the hardware version shown on your label. For a faster response, please share:
Our team will review the available manufacturer records and help identify the most relevant PDF for your equipment.
|
