Range suffix
Use suffix 02 as the 20 mm linear-range selection.
Item NO.:
400100-100-02Order(MOQ):
1Goods Stock:
10Payment:
T/TLead Time：
In stockWeight:
0.5KGDimension:
24.3x4.6x15.5cmDescription:
PROBEPrice:
AskA 4000 Series Air Gap Proximitor Sensor ordered for a 10.0 m system and the published 20 mm linear-range option.
400100-100-02 is a 4000 Series Air Gap Proximitor Sensor. The 100 field specifies a 10.0 m system length.
In the current ordering table, suffix 02 specifies the 20 mm (0.8 in) linear-range option. The family name references the Air Gap 50 mm Proximitor Sensor, but the exact suffix must govern the selected range.
Verify the connected Air Gap probe, extension-cable length, monitor interface and power requirements before replacing the sensor.
Use suffix 02 as the 20 mm linear-range selection.
Match the connected probe and cable to the 10.0 m sensor length.
Verify power, signal wiring and the connected Hydro Monitor input.
| Manufacturer | Bently Nevada |
|---|---|
| Component | Air Gap Proximitor Sensor |
| Product family | 4000 Series Air Gap Sensor System |
| System length option | 100 — 10.0 m |
| Linear range option | 02 — 20 mm (0.8 in) |
| Typical applications | Hydro-generator air-gap monitoring |
| Compatible monitoring context | 3500/46M Hydro Monitor and System 1 |
| Operating temperature | 0°C to +70°C (+32°F to +158°F) |
| Storage temperature | -35°C to +85°C (-31°F to +185°F) |
| Typical sensor mass | Approximately 380 g |
| Selection boundary | Probe, extension cable, sensor and monitor channel must be reviewed as one system |
| Place of shipment | Xiamen, China |
| Delivery Time | 1-3 days |
| Quantity | 100% New Original |
| Minimum Order Quantity | 1pc |
Keep the 10.0 m system length and suffix 02 linear-range option aligned with the installed probe and monitor input. Record the mounting position, cable route and all connected component labels instead of selecting by appearance.
Provide the complete nameplate, full product view, mounting point, both connector ends and the labels of the connected cable, sensor or monitor module.
Not on connector fit alone. Linear range, system length, temperature class and approval option must be checked against the complete order code.
Check channel power or configuration, connector locking, cable bends and shielding, then confirm that the probe, cable and sensor belong to one matched system.
Compare the carton and product labels, complete suffix, connector and cable condition, and supplied approval or inspection documents with the purchase order.
Send the complete model, quantity, required delivery date, destination, installation photos and connected component models, plus any available drawing or equipment list.
Share the exact nameplate, mounting dimensions, cable route, connected component labels and approval documents. ApterPLC can then prepare a model-focused quotation without treating connector fit or a family name as proof of interchangeability.
ApterPLC provides a one-year warranty on this item, giving buyers a clear support path after delivery.
Apter sells industrial automation parts through independent channels and is not an authorized distributor, dealer or representative of the brands shown. Product names, images and trademarks are used for identification only.
The English manufacturer document below is hosted by ApterPLC for product selection and technical review.
4000 Series Air Gap Sensor System Datasheet · 167885 Rev. POpen the English manufacturer datasheet for ordering information, system specifications and dimensions.Related Tags :
