Confirm the differential-expansion collar or ramp and available mounting space.
Item NO.:
330851-02-000-030-10-00-00Order(MOQ):
1Goods Stock:
12Payment:
T/TLead Time：
In stockWeight:
0.42KGDimension:
110x26x40cmDescription:
3300 XL 25 mm Proximity ProbePrice:
AskAn M30 x 2 unarmored 25 mm probe with a 30 mm case, 1.0 m FluidLoc lead and no-approval option.
M30 x 2 · 0 mm unthreaded · 30 mm case · 1.0 m lead · no armor · option 00330851-02-000-030-10-00-00 is an M30 x 2 probe in the 3300 XL 25 mm differential-expansion transducer family. It has a 30 mm case, 1.0 m FluidLoc lead and no stainless-steel armor.
Within the 25 mm system, 330851-02-000-030-10-00-00 supports a 12.7 mm linear range for differential-expansion measurements. The probe, 330854 extension cable and 330850 Proximitor Sensor are selected as one matched electrical system.
Before replacing 330851-02-000-030-10-00-00, compare the M30 x 2 mounting, 30 mm case reach, target arrangement, total system length and approval field, and protect connector cleanliness along the high-temperature route.
25 mm proximity probe
M30 x 2 case
0 mm unthreaded
30 mm case
1.0 m lead
No armor
No approvals
| VERIFIED TECHNICAL DATA | |
|---|---|
| Manufacturer | Bently Nevada |
| Product family | 3300 XL 25 mm proximity system |
| Component | Proximity probe |
| Probe case | M30 x 2 |
| Unthreaded length | 0 mm |
| Overall case length | 30 mm |
| Total lead length | 1.0 m |
| Probe cable | 75 ohm triaxial FluidLoc |
| Armor option | 00 - no armor |
| Family linear range | 12.7 mm (500 mil) |
| Family scale factor | 0.787 V/mm (20 mV/mil) |
| Recommended gap | 7.0 mm (275 mil) |
| Approval option | 00 - no approvals |
| SUPPLY & LOGISTICS | |
| Place of shipment | Xiamen, China |
| Delivery Time | 1-3 days |
| Quantity | 100% New Original |
| Minimum Order Quantity | 1pc |
Confirm the differential-expansion collar or ramp and available mounting space.
Match the 1.0 m probe to the selected 330854 cable and 330850 sensor.
Protect the FluidLoc lead, connectors and bend radius.
Verify the installed measurement through the required physical travel check.
When upgrading from an earlier system, the official guidance requires replacing the probe, extension cable and Proximitor Sensor as a complete 3300 XL 25 mm chain.
The 02 case option is M30 x 2. Verify the adapter and available case reach before the outage.
Use the 1.0 m probe lead with a 4.0 m or 8.0 m 330854 cable to match the selected 5.0 m or 9.0 m sensor.
It is the no-armor option. The final 00 is the no-approvals option, so both fields must be retained.
Differential-expansion accuracy depends on alignment and target geometry. Physical verification helps confirm range and mounting before protection is enabled.
Send the probe label, mounting adapter, target arrangement, extension-cable label and 330850 sensor label.
Complete labels and order fields are checked before quotation.
Probe, cable, rack and monitoring roles are reviewed together.
Commercial terms, documents and delivery are confirmed in writing.
Coverage begins on the shipment date unless the confirmed quotation states otherwise. Scope, exclusions and available remedy follow the written quotation and sales agreement.
Provide the complete 330851-02-000-030-10-00-00 label and order reference.
Add mounting, connector, rack and signal-chain photos.
Describe the symptom, operating state and first occurrence.
Include the applicable sales document and shipment date.
Share the complete product label and tell us whether you need a datasheet, user manual, wiring diagram or other technical document. Installed-system details can help us identify the most relevant available manufacturer material.
Our team will review the available documents and help match the closest useful file for 330851-02-000-030-10-00-00.
