Item NO.:
330780-91-00Order(MOQ):
1Goods Stock:
29Payment:
T/TLead Time：
In stockWeight:
0.2KGDimension:
8.8x3.6x7.1cmDescription:
PROXIMITY SENSORPrice:
AskSend the complete nameplate, installed system context, quantity and destination. We support new original, discontinued and difficult-to-source industrial parts.
Manager: JimPei
Exact-model engineering context
A nine-metre transducer route often ends in a crowded instrumentation cabinet, making rail access as important as cable length. 330780-91-00 combines the nine-metre 3300 XL 11 mm system selection with DIN mounting.
Probe lead and extension cable must add to nine metres before the channel is accepted. Inside the cabinet, the DIN position must leave access for terminals, testing, shield and grounding connections and the required cable bend.
Approval option 00 means no agency approval was requested in the catalog code; it does not waive the site's environmental or area-classification review. Commission from the probe toward the monitor so a mechanical or chain-length problem is not mistaken for a sensor fault.
Selection and installation decisions
Leave room for terminals, test access, shield routing and the cable bend.
Add the supported probe lead and extension-cable lengths from their complete labels.
The site still decides where and how the unapproved selection may be installed.
Official configuration and supply terms
| Manufacturer | Bently Nevada, a Baker Hughes business |
|---|---|
| Product family | 3300 XL 11 mm proximity transducer system |
| Product type | Proximitor Sensor |
| System length | 90 - 9.0 m |
| Mounting option | 1 - DIN mount |
| Agency approval selection | 00 - not required |
| Incremental scale factor | 3.94 V/mm (100 mV/mil) under documented system conditions |
| Linear range | 4.0 mm (160 mils) under documented system conditions |
| Sensor input | One supported 3300 XL 11 mm probe and extension-cable chain totaling nine metres |
| Place of shipment | Xiamen, China |
| Delivery Time | 1-3 days |
| Quantity | 100% New Original |
| Minimum Order Quantity | 1pc |
Model-relevant engineering themes
Record the exact probe and cable labels before monitor setup; scaling assumes the supported nine-metre transducer chain and documented target conditions.
Use the documented DIN base and terminal arrangement, preserve shield and grounding practice and keep the cable bend free of enclosure edges.
Stop and release boundary
A DIN clip and a nine-metre route do not by themselves prove compatibility. Stop if the exact component labels, target, cabinet wiring or site installation conditions cannot be verified.
Supported user task
Used in matched nine-metre 3300 XL 11 mm systems for supported longer-range position and vibration tasks where DIN-rail mounting is required.
Buyer, installer and engineer situations
Reserve DIN-rail width plus access for terminals, test points, shield and grounding connections and the minimum cable bend. Confirm that the enclosure door and adjacent devices do not load the cable.
No. The supported probe lead and extension cable must total nine metres for this sensor selection. Do not correct the mismatch by changing monitor scaling.
A loosened terminal, shield or ground change, disturbed probe gap, wrong total chain length or incomplete ClickLoc connection can shift the channel. Check them in that order before replacing hardware.
No. It states that an agency approval option was not requested. The site's area classification and installation rules still determine whether the item can be used.
Confirm target and probe gap, inspect the nine-metre component chain, verify sensor power, then check field output and monitor configuration. Stop if any stage cannot be reconciled with the official instructions.
Include full probe and extension-cable labels, DIN cabinet photographs, supply and terminal details, target material, quantity and destination.
ApterPLC supply capability
New original supply: Quality-focused sourcing and exact-model checks help protect the purchase decision.
Current, discontinued and scarce products: Our supply network supports routine and difficult-to-source automation parts.
Responsive after-sales service: We assist with delivery coordination, receipt questions and post-purchase technical communication.
Buyer search terminology
Search note: Common spelling, spacing and separator variants are listed for discovery only. Use the exact Product Model above for quotation and ordering.
Apter provides a 1-year warranty on every item we sell.
Our free 1-year warranty makes every Apter purchase a dependable, reliable investment in your company's future.
