Probe diameter and measurement family.
Item NO.:
330780-52-00Order(MOQ):
1Goods Stock:
21Payment:
T/TLead Time：
In stockWeight:
0.3KGDimension:
6.3x7x9.2cmDescription:
PROXIMITY SENSORPrice:
AskThe 52 option combines a 5.0 m system length with no mounting hardware. The cabinet mounting method must therefore be planned separately.
Bently Nevada 330780-52-00 is a 3300 XL 11 mm Proximitor Sensor configured for a 5.0 m total transducer system. It provides no mounting hardware and carries the no agency approval option.
The Proximitor Sensor is one part of a calibrated chain that also includes the matching probe and extension cable where applicable. For reliable longer-range 11 mm measurement, the family, total electrical length and connector arrangement must be reviewed together.
For replacement work, compare the complete 330780-52-00 label, mounting method and approval suffix with the installed unit. Photos of the probe, connectors and cabinet arrangement help prevent a visually similar but electrically incompatible selection.
Probe diameter and measurement family.
Matched total electrical system length.
Cabinet installation arrangement.
Nameplate and document option.
The 52 option combines a 5.0 m system length with no mounting hardware. The cabinet mounting method must therefore be planned separately.
| Manufacturer | Bently Nevada |
|---|---|
| Exact model | 330780-52-00 |
| Product family | 3300 XL 11 mm Proximity Transducer System |
| Component role | Proximitor Sensor / signal conditioner |
| Total system length | 5.0 m |
| Mounting option | No mounting hardware |
| Approval option | No agency approval option |
| Nominal scale factor | 3.94 V/mm (100 mV/mil) |
| Linear range | 4 mm (160 mil) |
| Place of shipment | Xiamen, China |
| Delivery Time | 1-3 days |
| Quantity | 100% New Original |
| Minimum Order Quantity | 1pc |
Capture the complete label, mounting arrangement, probe family, total system length and destination approval requirement.
Inspect connectors, cable route, cabinet clearance, target surface and grounding. Do not mix unmatched system families.
Verify wiring and supply against the official manual, then confirm the static gap and channel response with site procedures.
Axial thrust, ramp differential expansion, rod position or drop, tachometer, zero-speed and Keyphasor measurements in a matched 3300 XL 11 mm system.
Matched transducer-chain selection and maintenance replacement planning, with the exact order code verified before purchase.
Compare the full model, 5.0 m total length, no mounting hardware, probe family and connector arrangement. A matching product family alone is not enough.
Inspect the probe, extension cable, connectors and target condition. A damaged or mismatched component elsewhere in the chain can produce the same symptoms as a failed Proximitor Sensor.
It should not be treated as a general cross-family sensor. Use the matching 3300 XL 11 mm probe and cable combination defined by the manufacturer.
This version is supplied without mounting hardware, so the cabinet mounting method and clearances must be arranged separately.
The 00 option indicates no agency approval. If the site requires certification, review the approved variant before ordering.
Send the complete label, quantity, destination country and photos of the installed probe, connectors and mounting arrangement. Include any required certificate or document list.
We compare order code, installation and signal-chain details before quotation.
Commercial terms and available traceability are confirmed with the offer.
Availability and transport options are coordinated around the maintenance schedule.
ApterPLC supplies this product with a one-year limited warranty. Final scope, start date and claim handling follow the confirmed quotation, sales agreement and supplied warranty terms.
Keep the complete 330780-52-00 label, order reference, fault description and clear photos of the installed product and signal chain. Do not dismantle or alter the unit before receiving return instructions.
This official Baker Hughes / Bently Nevada document provides the product-family specifications, ordering information, mounting options and dimensional context used to verify 330780-52-00.
Exact version: 5.0 m · No mounting hardware · No agency approval option
