Build the five-metre chain
Use supported probe and extension-cable lengths whose total matches this sensor.
Item NO.:
330780-50-00Order(MOQ):
1Goods Stock:
33Payment:
T/TLead Time：
In stockWeight:
0.25KGDimension:
8x6.1x6.3cmDescription:
PROXIMITY PROBES SENSORPrice:
AskSend the complete nameplate, installed system context, quantity and destination. We support new original, discontinued and difficult-to-source industrial parts.
Manager: JimPei
Exact-model engineering context
Panel replacement succeeds only when the footprint and the electrical chain are reviewed together. 330780-50-00 is the panel-mount Proximitor Sensor for a documented five-metre 3300 XL 11 mm transducer system.
The supported probe lead plus extension cable must total five metres; a cable that merely reaches the panel is not enough. The sensor then converts the proximity signal into the conditioned output used by the connected monitor.
Before an outage, compare mounting-hole position, enclosure clearance, terminals, grounding and cable bend space. At startup, verify target material, probe gap, connector seating, sensor power and field wiring before changing monitor configuration.
Selection and installation decisions
Use supported probe and extension-cable lengths whose total matches this sensor.
Check mounting holes, connector access, terminal space and minimum cable bend clearance.
Verify target and gap first, then connectors, sensor power and field wiring.
Official configuration and supply terms
| Manufacturer | Bently Nevada, a Baker Hughes business |
|---|---|
| Product family | 3300 XL 11 mm proximity transducer system |
| Product type | Proximitor Sensor |
| System length | 50 - 5.0 m |
| Mounting option | 0 - panel mount |
| Agency approval selection | 00 - not required |
| Incremental scale factor | 3.94 V/mm (100 mV/mil) under documented system conditions |
| Linear range | 4.0 mm (160 mils) under documented system conditions |
| Sensor input | One supported 3300 XL 11 mm probe and extension-cable chain totaling five metres |
| Place of shipment | Xiamen, China |
| Delivery Time | 1-3 days |
| Quantity | 100% New Original |
| Minimum Order Quantity | 1pc |
Model-relevant engineering themes
The sensor supplies the conditioned proximity signal for supported displacement and vibration tasks; target and probe gap remain part of channel commissioning.
Confirm panel mounting, terminal identification, shield and grounding practice, test access and cable bend clearance before removing the old unit.
Stop and release boundary
Do not correct a five-metre chain mismatch with monitor calibration. Stop startup until the probe and extension-cable labels, panel arrangement, target and field wiring all agree with the official system.
Supported user task
Supports documented longer-range displacement and vibration measurements in a matched five-metre 3300 XL 11 mm transducer system with panel mounting.
Buyer, installer and engineer situations
Only after the mounting-hole pattern, enclosure clearance, connector access, terminals and minimum cable bend space are compared. A similar front view does not prove a drop-in replacement.
Use supported components whose probe lead plus extension cable equals five metres. Record both labels and do not add extra cable to gain reach.
Start with target material and probe gap, then check the five-metre total, ClickLoc seating, sensor power and field wiring. Do not change scaling while the chain remains unverified.
No. It means an agency approval option was not requested in the catalog code. The site must separately control classification, enclosure, wiring and installation requirements.
Stop if component lengths, target, mounting, terminals, shield, grounding or supply cannot be matched to the official instructions and site drawing.
Send all transducer-chain labels, panel and terminal photographs, target material, supply and wiring details, quantity and destination.
