Selection
- Match the complete part number, 150 mm unthreaded length, 230 mm case length and armored M10 x 1 geometry.
- Use the 5 m probe only with a 5 m 3300 XL Proximitor Sensor and verify any extension-cable plan before ordering.
Item NO.:
330104-15-23-50-02-00Order(MOQ):
1Goods Stock:
27Payment:
T/TLead Time：
In stockWeight:
0.07KGDimension:
23.5x20x3.5cmDescription:
reverse probePrice:
Ask330104-15-23-50-02-00 is a standard-mount, M10 x 1 armored probe for a matched Bently Nevada 3300 XL 8 mm proximity transducer system. Its ordering code specifies 150 mm of unthreaded length and a 230 mm overall case length.
330104-15-23-50-02-00 is a standard-mount, M10 x 1 armored probe for a matched Bently Nevada 3300 XL 8 mm proximity transducer system. Its ordering code specifies 150 mm of unthreaded length and a 230 mm overall case length.
330104-15-23-50-02-00 has a 5.0 m integral lead and a miniature ClickLoc coaxial connector on standard cable without a connector protector. Code 00 means that an agency approval option is not required for this configuration.
330104-15-23-50-02-00 should be selected as part of the complete measurement chain. The 5 m probe is intended for a 5 m Proximitor Sensor, while mounting geometry, target material, gap and monitor-channel settings must also match the installed system.
This configuration provides 150 mm of unthreaded reach within a 230 mm case. Compare both dimensions, the M10 x 1 bracket thread, available insertion depth and target clearance before selecting it for the existing mounting path.
No extension cable is normally part of that arrangement because the probe already has a 5.0 m integral lead. The installed Proximitor Sensor must also be the documented 5 m version.
The 150 mm unthreaded reach and 230 mm case can change tip position and bracket fit. The M10 x 1 thread, 5 m electrical length, ClickLoc interface, target material and monitor setup must remain suitable as well.
Use a route that maintains at least the 25.4 mm cable bend radius and keeps side load away from the ClickLoc joint. The armor protects the lead mechanically, but it does not remove the bend-radius limit.
For a radial-vibration channel, establish the documented gap and bias under a known machine condition, then record the channel response. A later comparison is meaningful only when target, speed, load and acquisition settings are comparable.
Separate mechanical fit from the electrical chain: review insertion depth, probe gap, target surface and case seating, then check ClickLoc seating, lead continuity, the 5 m Proximitor and channel configuration.
The supplied product is covered for 12 months under ApterPLC sales terms. Keep the complete product label, original packaging and transaction record so the exact unit can be identified quickly if support is needed.
Use this selected official Bently Nevada document to review the ordering structure, configuration boundaries, interfaces, installation details and technical limits that apply to 330104-15-23-50-02-00.
|
