Use the 70 mm case and zero unthreaded length to compare the exact bracket-to-target geometry.
Item NO.:
330104-00-07-10-02-COrder(MOQ):
1Goods Stock:
15Payment:
T/TLead Time：
In stockWeight:
0.14KGDimension:
2x18.7x12.8cmDescription:
SENSORPrice:
AskAn armored M10 x 1 probe with a 70 mm case, 1.0 m standard lead and a nameplate-controlled CN suffix.
M10 x 1 · 70 mm case · 1.0 m lead · standard ClickLoc · CN label controlledArmored cable protection and a medium-length metric body define 330104-00-07-10-02-CN. The M10 x 1 probe has a 70 mm case with no unthreaded section, giving it a different mechanical fit from shorter or long-reach 330104 variants.
The 1.0 m standard lead on 330104-00-07-10-02-CN works with the extension cable and 3300 XL 8 mm Proximitor Sensor as a calibrated chain. The extension cable length should therefore be chosen from the installed sensor total-length option.
CN is not decoded in the current public ordering table. A quote for 330104-00-07-10-02-CN should preserve that suffix and use the full label and offered documents to establish its exact regional or certification package.
M10 x 1; with armor
0 mm unthreaded length
70 mm case
1.0 m total lead
Standard ClickLoc cable
Nameplate-controlled suffix
| MODEL-RELEVANT TECHNICAL DATA | |
|---|---|
| Manufacturer | Bently Nevada |
| Product family | 3300 XL 8 mm proximity transducer system |
| Component | Armored standard-mount probe |
| Probe thread | M10 x 1 |
| Unthreaded length | 0 mm |
| Overall case length | 70 mm |
| Total lead length | 1.0 m |
| Connector / cable | Miniature ClickLoc; standard cable |
| Family linear range | 2.0 mm (80 mil) |
| Minimum bend radius | 25.4 mm |
| Suffix boundary | CN is not decoded in the current public ordering table |
| SUPPLY & LOGISTICS | |
| Place of shipment | Xiamen, China |
| Delivery Time | 1-3 days |
| Quantity | 100% New Original |
| Minimum Order Quantity | 1pc |
Use the 70 mm case and zero unthreaded length to compare the exact bracket-to-target geometry.
Check bend radius and service clearance for the armored lead before selecting a visually similar probe.
Match CN from the label and documents rather than converting it to another agency code by assumption.
Add the 1.0 m probe lead to the extension cable and match that total to the installed sensor.
Support the armor so motion and weight do not transfer into the probe body or connector.
Restore the documented gap and review the channel response before changing monitoring settings.
The CN suffix is the main evidence boundary. The probe geometry is decodable from the standard fields, but the suffix must remain tied to the actual nameplate and supplied document package.
The mechanical fields may align, but the suffix package should not be treated as equivalent without the delivered label and documentation.
Bracket depth, thread engagement and the 70 mm case are the most useful mechanical checks before changing the mount.
Use the installed Proximitor Sensor total length and subtract the 1.0 m probe lead; connector appearance alone is not enough.
Unsupported weight, a tight bend or repeated rubbing can load the cable and connector even when the sensing tip remains undamaged.
The public order table does not state that equivalence. The actual certificate package should guide the decision.
Clear photos of the complete probe label, armor route, connector and both downstream component labels provide the strongest context.
Complete labels and order fields are compared before quotation.
Probe, cable, sensor and transmitter roles are reviewed together.
Commercial terms, documents and delivery are confirmed in writing.
Coverage begins on the shipment date unless the confirmed quotation states otherwise. Scope, exclusions and the available remedy follow the written quotation and sales agreement.
Provide the complete 330104-00-07-10-02-CN label and order reference.
Add mounting, connector and signal-chain photos.
Describe the symptom, operating state and first occurrence.
The compact PDF keeps the official manufacturer pages that matter most for this model: product identity, order-code structure, system context and the relevant specifications. It omits unrelated catalog pages so the key evidence is easier to find.
