330104-00-07-05-02-00 is a Bently Nevada 3300 XL 8 mm metric proximity probe with an armored cable construction. The product page leads with cable-route and delivered-configuration control because those conditions affect both the installation plan and the purchase request.

For 330104-00-07-05-02-00, the 70 mm case, 0 mm unthreaded section and 0.5 m lead should be considered together with the available route and service access. Cable protection reduces exposure but does not remove the need for clearance at bends, connectors or removal points.

330104-00-07-05-02-00 should be quoted from the complete ordering code and the project’s mounting context. Its 0.5 m integral lead is only one component of the completed measurement chain and must be paired with the correct official extension cable and matched Proximitor Sensor.

Installation handoff

Control the route before release.

ROUTEPlan protected routing and service clearance together.

MARKINGUse the complete code for the delivered configuration review.

HANDOFFInclude mounting and chain context in the RFQ.

Configuration focus

Key Features

Protected routePlan cable protection and clearance as the same installation decision.

Configuration controlUse the complete order code and project context for supply review.

System completionKeep the selected probe chain aligned with the required total system length.

Verified configuration

Technical Specifications

Manufacturer	Bently Nevada, a Baker Hughes business
Product family	3300 XL 8 mm proximity transducer system
Product type	Metric proximity probe
Ordering family	330104
Thread	M10 × 1
Cable armor	with armor
Unthreaded length	0 mm
Overall case length	70 mm
Integral cable length	0.5 m
Cable / connector option	02 — miniature coaxial ClickLoc connector, standard cable
Agency option	00 — approval not required
Place of shipment	Xiamen, China
Delivery Time	1-3 days
Quantity	100% New Original
Minimum Order Quantity	1pc

Source: Baker Hughes Bently Nevada 3300 XL 8 mm Proximity Transducer System Data Sheet, 141194 Rev. AM. Values are limited to the manufacturer’s published ordering-code definitions for this configuration.

Technical note

Route and marking boundary.

Engineering checkpoint

For 330104-00-07-05-02-00, armor protects the cable route but does not eliminate bend, pinch-point or connector-access limits. Preserve the protected path and service clearance together; stop when the installed route forces loading or trapping of the cable.

Buyer and engineer support

Frequently Asked Questions

An installer has a bracket originally sized for a shorter body. Can 330104-00-07-05-02-00 be released on thread size alone?

No. Its 70 mm case must also leave space for locknut adjustment, the armored cable exit and future removal. Compare the complete mechanical envelope with the drawing first.

Can procurement use any M10 × 1 probe when 330104-00-07-05-02-00 is not immediately available?

No. Thread form alone does not establish compatibility. Match the 70 mm body, 0.5 m lead, cable option, required total system length and delivered marking to the installed configuration.

How should a protected cable route for 330104-00-07-05-02-00 be prepared near moving equipment?

Keep the armored cable supported and clear of pinch points, sharp edges and bend stress. Do not use the armor as a reason to omit routing clearance or connector access.

What should a purchaser send when asking for 330104-00-07-05-02-00 as a shutdown spare?

Provide the full installed nameplate, mounting dimensions, required total system length, existing extension and Proximitor labels, quantity and destination. Those details prevent a visually similar but wrong configuration.

What should a buyer include in an RFQ for 330104-00-07-05-02-00 to avoid an incorrect replacement?

Send the complete nameplate photograph, mounting drawing, target details, required total system length, existing Proximitor and extension labels, quantity, destination and any site approval requirement.

How does the 0 mm unthreaded section of 330104-00-07-05-02-00 affect a replacement decision?

It changes the usable mounting stack relative to the 70 mm case. Compare engagement, locknut location and target reach on the actual drawing before releasing the order.

Our drawing has an M10 × 1 port. What should the installer measure before fitting 330104-00-07-05-02-00?

Compare the 70 mm case with bracket thickness, locknut travel, target location and rear cable clearance. Stop before installation if the drawing does not leave safe adjustment for the operating gap.

Supply support

Project Supply Support

We support quality-focused sourcing for current, discontinued and difficult-to-find industrial automation parts. For an exact-match review, provide the complete model, clear nameplate photograph, mounting drawing, required system length, quantity and destination.
