Armored lead
Confirm armor routing, connector clearance and minimum bend requirements.
Item NO.:
330104-00-06-10-02-0Order(MOQ):
1Goods Stock:
11Payment:
T/TLead Time：
In stockWeight:
0.22KGDimension:
8.8x3.5x7cmDescription:
PROBEPrice:
AskAn armored metric proximity probe with a 60 mm case and a 1.0 m lead.
330104-00-06-10-02-00 is the armored metric-probe construction in the 3300 XL 8 mm proximity transducer system. It uses an M10 × 1 thread.
The 00 and 06 fields specify 0 mm unthreaded length and a 60 mm overall case. The 10 field gives a 1.0 m lead, while option 02 is standard cable without a connector protector.
The final 00 is the published no-approval-required selection. Check the installed extension cable and Proximitor Sensor before substitution.
Confirm armor routing, connector clearance and minimum bend requirements.
The case length controls bracket position and probe withdrawal space.
The extension cable must complete the Proximitor Sensor electrical length.
| Manufacturer | Bently Nevada |
|---|---|
| Product family | 3300 XL 8 mm proximity transducer system |
| Probe construction | Armored metric probe |
| Thread | M10 × 1 |
| Unthreaded length | 0 mm |
| Overall case length | 60 mm |
| Total lead length | 1.0 m |
| Connector / cable option | Standard ClickLoc; no connector protector |
| Approval option | 00 — not required |
| Matched-system linear range | 2.0 mm (80 mils) |
| Nominal average scale factor | 7.87 V/mm (200 mV/mil) |
| Matched-system frequency response | 0 to 10 kHz, +0 / -3 dB |
| Armor construction | Flexible AISI 302 or 304 stainless steel with FEP outer jacket |
| Probe tip material | Polyphenylene sulfide (PPS) |
| Probe case material | AISI 303 or 304 stainless steel |
| Probe cable | 75 Ω triaxial, FEP insulated |
| Connector material | Gold-plated brass or gold-plated beryllium copper |
| Minimum cable bend radius | 25.4 mm (1.0 in) |
| Probe case-to-lead tensile strength | 330 N (75 lbf), maximum rated |
| Connector tightening torque | 0.565 N·m (5 in·lbf), maximum |
| Standard probe temperature range | -52°C to +177°C (-62°F to +350°F) |
| Minimum flat target diameter | 15.2 mm (0.6 in) |
| Recommended minimum shaft diameter | 76.2 mm (3.0 in) |
| Place of shipment | Xiamen, China |
| Delivery Time | 1-3 days |
| Quantity | 100% New Original |
| Minimum Order Quantity | 1pc |
Yes. The 330104 construction adds flexible stainless-steel armor with an FEP outer jacket.
It matches a 60 mm overall case and M10 × 1 thread when the bracket also provides enough armor and connector clearance.
The published minimum cable bend radius is 25.4 mm, so a 15 mm bend would be too tight for the specified cable route.
Option 02 is the standard ClickLoc cable without a connector protector, so environmental protection should be planned separately.
Select the extension cable so the probe lead and cable total equals the Proximitor Sensor electrical length.
Include the armored construction, M10 × 1 thread, 60 mm case, 1.0 m lead and connected extension-cable and Proximitor Sensor models.
Share the exact nameplate, mounting or route dimensions, connected component labels and approval documents. ApterPLC can then prepare a model-focused quotation without treating a similar connector or family name as proof of interchangeability.
ApterPLC provides a one-year warranty on this item, giving buyers a clear support path after delivery.
Apter sells industrial automation parts through independent channels and is not an authorized distributor, dealer or representative of the brands shown. Product names, images and trademarks are used for identification only.
This model-specific PDF brings together the relevant Baker Hughes ordering-code and technical pages for 330104-00-06-10-02-00. Use it to verify the armored probe construction, 60 mm case, 1.0 m lead, ClickLoc option and approval selection before ordering or replacement.
Open the 330104-00-06-10-02-00 Datasheet (PDF)|
