Item NO.:
330101-00-60-10-02-00Order(MOQ):
1Goods Stock:
28Payment:
T/TLead Time：
In stockWeight:
0.1KGDimension:
2x1.5x112cmDescription:
PROXIMITY PROBEPrice:
Ask3300 XL 8 mm proximity transducer system · 6.0 in case · official stocked configuration
Manager JimPei · Nameplate, mounting and system-length review for maintenance and project purchases.
330101-00-60-10-02-00 is a manufacturer-listed 3300 XL 8 mm forward-mount probe with a 3/8-24 UNF thread, zero unthreaded length, a 6.0 in overall case and a 1.0 m standard integral cable. Its option 02 ClickLoc lead is unarmored and has no separate connector protector.
330101-00-60-10-02-00 is an official stocked long-case configuration. The six-inch threaded body must be checked for alignment, engagement, adjustment range and rear cable space; the one-metre lead must then be completed to the exact Proximitor system length.
The exact full code appears in the manufacturer’s recommended stocked-probe list.
Provides substantial reach for deep mounting arrangements.
Uses the official extension cable to complete a five- or nine-metre chain.
Case length only defines mounting geometry. The sensing range and gap remain those of the 3300 XL 8 mm system; set the probe from the approved gap procedure, not from body insertion depth.
| Manufacturer | Bently Nevada, a Baker Hughes business |
|---|---|
| Product family | 3300 XL 8 mm |
| Product type | Forward-mount proximity probe |
| Thread | 3/8-24 UNF |
| Cable armor | Not included |
| Unthreaded length | 0.0 in |
| Overall case length | 6.0 in |
| Integral cable length | 1.0 m |
| Connector / cable | Miniature coaxial ClickLoc / standard cable |
| Connector protector | Not selected |
| Agency option | 00 — not required |
| Place of shipment | Xiamen, China |
| Delivery Time | 1-3 days |
| Quantity | 100% New Original |
| Minimum Order Quantity | 1pc |
Commercial packed weight and packed dimensions remain in the page logistics fields unless the manufacturer publishes model-specific packing data.
Use the six-inch case only where the mechanical drawing supports its alignment and adjustment. Keep engagement within the documented limit and preserve rear access for locknuts and cable routing.
After installation, verify total electrical length, connector seating, gap voltage and target condition. A long body does not change the required electrical chain or monitor scaling.
No. The longer case changes mounting reach, not the 3300 XL 8 mm sensing range. Confirm the mechanical fit and set the normal probe gap using the approved commissioning method.
Allow space for the full six-inch body, locknut adjustment, connector access and a cable bend of at least the manufacturer minimum. Revise the mounting plan if the lead would be forced sharply against nearby hardware.
Reuse it only when its label, condition and length complete the same five- or nine-metre system required by the installed Proximitor. Replace it if the code or connector condition cannot be confirmed.
The probe may be at the wrong physical gap, the target may differ, or the electrical chain may have a wrong length or loose connector. Check those conditions before touching monitor calibration.
This exact code carries option 00. Select and verify the manufacturer’s approved suffix instead when the project requires CSA, ATEX or IECEx marking.
Send the full code and label photograph, mounting-depth and rear-clearance drawings, system-length and Proximitor labels, route conditions, quantity, condition and destination.
Apter provides a 1-year warranty on every item we sell.
Our free 1-year warranty makes every Apter purchase a dependable, reliable investment in your company's future.
Apter sells industrial automation parts, including new and discontinued products, and purchases these products through independent channels. Apter is not an authorized distributor, dealer or representative of the manufacturers shown on this site. Product names, images, trademarks, brands and logos belong to their respective owners and are used only for identification; their use does not imply affiliation or authorization.
3300 XL 8 mm Proximity Transducer System — 141194 Rev. AM
Need the correct revision or configuration document? Send the complete model and installed-system details to Manager JimPei.
